BPS1340Aw
BPS1340AW Ignition Coil Diagram
- Speed control module cpl. - 5100049552×1
- Governor lever - 5100005425×1
- ROD-GOVERNOR CONTROL - 5000071068×1
- Tension spring - 5100049553×1
- Tension spring - 5100049554×1
- Governor lever - 5100049555×1
- WASHER-CONCAVE - 5000071058×1
- WASHER - 5000071057×1
- HOLDER-REMOTE CONTROL CABLE - 5000071062×1
- SPACER - 5000071064×1
- SPRING-ADJUSTING - 5000054088×1
- Spring - 5000071667×1
- SCREW M6 X 12,HX.FLANGE HD. - 5000053990×1
- Screw - 5100000451×1
- SCREW M6 X 20,HX.FLANGE - 5000071055×1
- NUT-LOCK M6,HEX. - 5000072782×1
- SCREW-PAN 5 X 16 - 5000110112×1
- SCREW M5 X 25 - 5000081990×1
- NUT M6,HEX,FLANGE - 5000071056×1
- Bracket - 5100029313×1
