BS60-4s RMR,11PL-SH,GRN/GRAY,EU 40

BS60-4S Air Cleaner cpl. Diagram

Exploded parts diagram of the Air Cleaner cpl. of a Wacker Neuson BS60-4S, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 135000156979
    $97.14
    SHOCKMOUNT x-5100032053 - 5000156979×2
  • 185000192868
    $60.35
    CABLE-CRANE LIFT X 5100032051 - 5000192868×1
  • 215200003982
    $70.21
    Filter-Air Box,4 Stroke - 5200003982×1
  • 795000011541
    $1.06
    SCREW M8 X 30 SOC.HD. - 5000011541×4
  • 905000010367
    $0.10
    NUT-LOCK M8 HEX - 5000010367×2
  • 1035100015853
    $183.73
    Bracket-Shockmount,Right P-5000112007 - 5100015853×1
  • 1045100015850
    $83.35
    Bracket-Shockmount,Left P-5000112007 - 5100015850×1
  • 1145000156981
    $0.92
    GROMMET-ROUND - 5000156981×4
  • 1245000156394
    $10.07
    brace - 5000156394×1
  • 1315000161246
    $0.33
    SCREW M8 X 14 HX.HD. - 5000161246×4
  • 1315000033198
    $0.32
    WASHER-LOCK B8 - 5000033198×4
  • 2225000011457
    $1.49
    SCREW M8 X 25 HX.HD. - 5000011457×6
  • 2225000033198
    $0.32
    WASHER-LOCK B8 - 5000033198×6
  • 2235000012361
    $0.23
    SCREW M8 X 16 HX.HD. - 5000012361×4
  • 2235000033198
    $0.32
    WASHER-LOCK B8 - 5000033198×4
  • 2715200003939
    $4.74
    X-5200023647-Hose-Fuel Low Perm - 5200003939×1
  • 2725000111458
    $0.03
    WRAP-CABLE TIE 3.6X203MM,BLACK - 5000111458×1
  • 4015000164398
    $2.67
    SCREW-FILTER,AIR BOX - 5000164398×2
  • 4025200007043
    $41.35
    COVER-FILTER,AIR BOX ASSEMBLY - 5200007043×1
  • 4035200003062
    $16.37
    Filter-Air,Element - 5200003062×1
  • 4045200007044
    $1.44
    ELEMENT-PREFILTER - 5200007044×1
  • 4055200007045
    $7.10
    FOAM-FILTER - 5200007045×1
  • 4065200007041
    $51.85
    BASE-AIR BOX,4-CYCLE - 5200007041×2
  • 4075000164397
    $4.33
    CLIP-FILTER,AIR BOX - 5000164397×2
