CT48AGP-E TROWEL

CT48AGP-E Air Cleaner Diagram

Exploded parts diagram of the Air Cleaner of a Wacker Neuson CT48AGP-E, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15000071027
    $12.72
    NUT-WING M6,AIR CLEANER COVER - 5000071027×1
  • 25000082833
    $72.77
    COVER-AIR CLEANER - 5000082833×1
  • 35000071621
    $7.20
    NUT-WING M6 - 5000071621×1
  • 45000072343
    $6.93
    GROMMET .240 ID,METALCLAD - 5000072343×1
  • 55000075847
    $22.81
    ELEMENT-AIR CLEANER - 5000075847×1
  • 65000078887
    $16.38
    ELEMENT-FOAM PRECLEANER - 5000078887×1
  • 75000074761
    $15.63
    SPACER-CARBURETOR MOUNT - 5000074761×1
  • 85000151693
    $54.42
    TUBE-BREATHER,11MM X 105MM - 5000151693×1
  • 95000071036
    $2.43
    SCREW M6 X 20 W/FW,HEX.FLANGED - 5000071036×1
  • 105000074744
    $3.77
    GASKET-AIR CLEANER MOUNT - 5000074744×1
  • 115000082835
    $19.35
    MOUNT-AIR CLEANER - 5000082835×1
  • 125000071035
    $5.49
    Sleeve - 5000071035×1
  • 135000076372
    $5.61
    RING-COLLAR - 5000076372×2
  • 145000071056
    $1.01
    NUT M6,HEX,FLANGE - 5000071056×2
  • 155000081227
    $6.16
    LABEL-CHOKE CONTROL - 5000081227×1
  • 165000082834
    $46.20
    MOUNT-AIR CLEANER - 5000082834×1
