FUH70/6/042 SC

FUH70/6/042SC Steerage cpl. Diagram

Exploded parts diagram of the Steerage cpl. of a Wacker Neuson FUH70/6/042SC, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15100046196Not stocked
    between deck×1
  • 25100048326Not stocked
    Plate×1
  • 35100051534Not stocked
    LED Housing×1
  • 45100047450Not stocked
    Connecting pin cpl.×9
  • 55100047452Not stocked
    Covering×2
  • 65000219501Not stocked
    Protective cap×2
  • 75000109579
    $41.11
    PORT-CEE SOCKET - 5000109579×2
  • 85000069294
    $0.19
    SCREW-SELF TAPPING,9X25 C-H-VZ - 5000069294×8
  • 95000213543
    $0.35
    SCREW-PAN HD. - 5000213543×8
  • 105000010625
    $0.14
    WASHER B5.3 FLAT - 5000010625×4
  • 115100054190Not stocked
    clamping plate×1
  • 125100058423Not stocked
    Locking plug×2
