G230 Generator, Custom T4i

G230 Option-Camlock Diagram

Exploded parts diagram of the Option-Camlock of a Wacker Neuson G230, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 935000193946
    $39.04
    PANEL CP EMF, XL - 5000193946×1
  • 1405000193951
    $4,055.15
    CAMLOCK BOX ASSY XL - 5000193951×1
  • 2315000152979
    $16.84
    STRAP GROUND 15IN - 5000152979×1
  • 5475000193936
    $255.71
    CLAMP-WIRE, 3 - 5000193936×1
  • 6735000193941
    $58.83
    INSULATOR REAR CL BOX, XL - 5000193941×1
  • 6745000193942
    $36.23
    INSULATOR RIGHT CL BOX, XL - 5000193942×1
  • 8335000028949
    $0.29
    SCREW M6 X 16,HX.HD,SER.FLG - 5000028949×2
  • 8385000028404
    $0.26
    SCREW M8 X 20,HX.HD,SER.FLG - 5000028404×2
  • 8885000161194
    $0.29
    SCREW M8X25 HX.HD.,A2 304,SST - 5000161194×4
  • 9145000029117
    $0.03
    NUT-LOCK M6,HEX,SERR,FLANGE - 5000029117×2
  • 9165000030066
    $0.16
    NUT-LOCK M8,HEX,SERR.,FLANGE - 5000030066×6
  • 9635000158899
    $0.07
    WASHER M8 FLAT,SST - 5000158899×4
