G25 Generator, Custom T4i

G25 Option-Northslope Diagram

Exploded parts diagram of the Option-Northslope of a Wacker Neuson G25, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15000183491Not stocked
    Cover plate×1
  • 25000162964
    $219.12
    LIGHT-BEACON,STROBE - 5000162964×1
  • 35000183496
    $376.11
    LIGHT-BEACON,STROBE,RED - 5000183496×1
  • 45000183570Not stocked
    Light bracket×1
  • 55000166730Not stocked
    Light×1
  • 85000183637
    $200.74
    WIRING HARNESS-OPTION,NS - 5000183637×1
  • 95000183494
    $27.15
    PLUG-HARNESS ADAPTER,NS - 5000183494×1
  • 4305000154302
    $75.96
    FITTING-M20 MALE X 1/2 NPT - 5000154302×1
  • 5065000180767
    $177.21
    HEATER-PAD 3 ROUND - 5000180767×1
  • 6185000180765
    $470.58
    FITTING-CRANKCASE OIL DRAIN,QD - 5000180765×1
  • 6205000180857
    $5.16
    FITTING-1/2 JIC M X 1/2 NPT M - 5000180857×1
  • 6215000180858
    $20.26
    FITTING-1/2 JIC F X 1/2 BRB,90 - 5000180858×1
  • 6235000180860
    $10.72
    FITTING-1/2 JIC F X 1/2 BRB - 5000180860×1
  • 6255000180861
    $63.52
    FITTING-3/4 NPT X 1/2 JIC M - 5000180861×1
  • 6465000180859
    $31.65
    HOSE-1/2 X36 PUSH LOK,HI TEMP - 5000180859×1
  • 7865000111458
    $0.03
    WRAP-CABLE TIE 3.6X203MM,BLACK - 5000111458×9
  • 8285000154516
    $0.09
    SCREW M5X16-4.8-H PAN HD ZP - 5000154516×4
  • 8535000157021
    $0.57
    SCREW M8 X 14,HX.HD,SERR.FLG - 5000157021×2
  • 8795000171457
    $0.06
    SCREW #10 X 3/4 PHIL PAN - 5000171457×1
  • 8815000159811
    $0.95
    SCREW M5X16 HX HD SERR FLG ZP - 5000159811×4
  • 9125000010369
    $0.03
    NUT-LOCK M5 HEX. - 5000010369×4
  • 9165000030066
    $0.16
    NUT-LOCK M8,HEX,SERR.,FLANGE - 5000030066×2
  • 9945000077809
    $0.30
    NUT 3/8-24,HEX.JAM STAINLESS - 5000077809×1
