G70 Generator Hertz,Cold Weather

G70 Option-Fuel Quick Disconnect Diagram

Exploded parts diagram of the Option-Fuel Quick Disconnect of a Wacker Neuson G70, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 165200001436
    $1,834.47
    PANEL-ENCL FRT WLDT,MED,YEL P-5000112006 - 5200001436×1
  • 3135200001626
    $164.18
    HOSE ASSY-3/8 FUEL RETURN ML/XL - 5200001626×1
  • 3145200001625
    $110.55
    HOSE ASSY-3/8 FUEL FEED ML/XL - 5200001625×1
  • 4205200001622Not stocked
    Adapter fitting×2
  • 5115000153746
    $1.14
    CLAMP-TUBING .625 - 5000153746×1
  • 5425200001623
    $31.87
    COUPLER-ISO 7241-1B 3/8 MALE - 5200001623×2
  • 5435200001624
    $81.09
    COUPLER-ISO 7241-1B 3/8 FEMALE - 5200001624×2
  • 5465300000035Not stocked
    Cover cpl.×1
  • 7865000111458
    $0.03
    WRAP-CABLE TIE 3.6X203MM,BLACK - 5000111458×1
  • 7995200001628
    $0.08
    SCREW M4X20,Soc FL HD,Zinc - 5200001628×4
  • 8385000028404
    $0.26
    SCREW M8 X 20,HX.HD,SER.FLG - 5000028404×1
  • 9115000010370
    $0.03
    NUT-LOCK M4 HEX. - 5000010370×4
  • 9165000030066
    $0.16
    NUT-LOCK M8,HEX,SERR.,FLANGE - 5000030066×1
  • 9525000010628
    $0.02
    WASHER A4.3 FLAT - 5000010628×4
