HX 60 Heat Exchanger, 230 V

HX60 Wiring cpl. Diagram

Exploded parts diagram of the Wiring cpl. of a Wacker Neuson HX60, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 115000177175Not stocked
    Enclosure×1
  • 3005000166792Not stocked
    Plug×1
  • 3015000170230Not stocked
    Cord×1
  • 3025000170231Not stocked
    Cord grip×1
  • 3265000172211Not stocked
    Relay×1
  • 3275000172637Not stocked
    Breaker×1
  • 3285000172391Not stocked
    Cover×1
  • 3325000170662Not stocked
    Terminal×1
  • 3385000166833Not stocked
    Terminal×2
  • 3505000172587Not stocked
    Motor×1
  • 3755000177772Not stocked
    Temperature control×1
  • 3765200001867Not stocked
    Temperature sensor×1
  • 3775000177410Not stocked
    Wiring harness×1
  • 4225000167725Not stocked
    Cable tie×3
  • 4505000173878Not stocked
    Nut w/washer×2
