IRflex38/230/5r

IRFLEX38/230/5R Protective hose cpl. Diagram

Exploded parts diagram of the Protective hose cpl. of a Wacker Neuson IRFLEX38/230/5R, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15100072221Not stocked
    Supply line cpl.×1
  • 25000208140
    $684.32
    Flexible tube - 5000208140×1
  • 35000128141
    $5.39
    CLAMP - 5000128141×1
  • 45000128141
    $5.39
    CLAMP - 5000128141×1
  • 55100005155
    $1.12
    Spacer 11x3x50 - 5100005155×1
  • 65100029394
    $39.48
    Screw connection cpl. - 5100029394×1
  • 75000218500
    $0.13
    Screw-Pan Head - 5000218500×3
  • 85000200988
    $0.40
    WASHER-LOCK,TOOTHED - 5000200988×3
  • 95000203577
    $0.58
    SCREW-PRESSURE - 5000203577×1
  • 105000203579
    $0.21
    RING-THRUST - 5000203579×1
  • 115000202933
    $10.48
    PLUG-4 HOLE - 5000202933×1
  • 125000066351
    $0.17
    End sleeve for strand E 1,5- 8 - 5000066351×3
  • 135000202516
    $1.35
    TERMINAL-SPLICE 24.5-2.5 - 5000202516×3
