LTC4L-LIGHT TOWER,LOMBARDINI
LTC4L Timing/Speed Governor Diagram
- ROCKER ARM ASSEMBLY - 5000155696×1
- rocker arm - 5000159248×3
- screw - 5000159482×6
- nut - 5000159272×6
- STUD - 5000159483×3
- nut - 5000159275×3
- ROCKER-INJECTOR - 5000159249×3
- SHAFT SUPPORT - 5000159447×4
- washer - 5000159350×4
- plug - 5000159274×4
- STUD - 5000159333×4
- pin - 5000159443×1
- plug - 5000159456×2
- rocker arm - 5000159248×3
- sleeve - 5000159257×1
- CAM-INJECTOR - 5000159279×1
- SCREW - 5000159472×1
- O-RING - 5000159234×1
- flange - 5000159282×1
- SCREW M6 X 1 X 20 - 5000159468×3
- PULLEY-DRIVE W/KEY - 5000159338×1
- BELT-TIMING - 5000155697×1
- SEAL-LIP - 5000159240×1
- SCREW M6 X 1 X 16 - 5000159467×3
- COVER-GOVERNOR - 5000159265×1
- O-RING - 5000159239×1
- BEARING-BALL - 5000159267×1
- plate - 5000159324×1
- SCREW M6 X 1 X 16 - 5000159478×3
- GOVERNOR-SPEED - 5000155698×1
- 345000159310Not stockedSleeve×1
- sleeve - 5000159251×1
- 365000159269Not stockedBearing×1
- screw - 5000159481×1
- washer - 5000159349×1
- plug - 5000159274×1
- STUD - 5000159334×1
- washer - 5000159344×1
- PULLEY-JOCKEY - 5000159284×1
- SHAFT-ROCKER ARM - 5000160218×1
- camshaft - 5000155699×1
