LTV4L
LTV4L 240W LED-Licht Diagram
- DISC-LIGHT MOUNT - 5200002026×4
- WASHER-B19 FLAT - 5000176448×4
- NUT-LOCK,M18 HEX - 5000172920×4
- LIGHT FIXTURE 240W LED FLOOD - 5100057272×4
- LENS - LED LIGHT - 5100061815×1
- LENS GASKET - 5100061814×1
- PCB Board - 5100061813×1
- Housing - 5100061812×1
- Gasket - 5100061811×1
- SCREW - 5100061809×4
- LED DRIVER - 5100061808×1
- Cover - 5100061807×1
- SCREW - 5100061806×9
- Wiring Cap - 5100061805×3
- BRACKET, U TYPE - 5100061804×1
- STRAIN RELIEF - 5100061803×1
- Cable - 5100061802×1
- BREATHER - 5100061801×1
- SCREW - 5100061800×18
- Serrated Lock Washer - 5100061799×2
- SCREW - 5100061798×16
- WASHER - 5100061797×2
- Spring Washer - 5100061796×2
- BOLT - 5100061793×2
