Drive Engine M3000/120/UL
M3000/120/UL Housing cpl. Diagram
- Housing Assembly, M3000 - 5100004408×1
- NUT-WELD - 5000083048×1
- Filter Element - 5100003047×1
- Cover cpl. - 5100003046×1
- ELEMENT-AIR FILTER - 5000053950×2
- INSERT-BRUSH HOLDER,BRASS - 5000054362×2
- BRUSH-CARBON 115V - 5000078485×2
- O-RING 25 X 1.5-70 Sh - 5000038765×2
- KIT-BRUSH COVER REPLACEMENT - 5000078697×2
- SCREW M5 X 30 - 5000202539×6
- SCREW M5 X 80 - 5000202540×6
- CAP-SCREW HEAD - 5000202124×2
- NUT M5,ACORN CAP - 5000081277×12
- STUD-BARBED 5 X 20 - 5000202123×4
- Cap - 5100003532×1
- Brace cpl. - 5100003533×2
- Oval head screw - 5100001546×8
- SCREW M5 X 30 - 5000202539×2
