PT6LT(I)-PUMP W/TRAILER,T4, EU
PT6LT(I) Timing/Speed Governor Diagram
- NUT-FLANGED - 5000063700×8
- PUMP-INJECTION - 5000160379×4
- STUD - 5200009479×8
- O-ring - 5000159233×3
- plate - 5000159325×1
- WASHER-COPPER - 5000159300×4
- screw - 5000159473×8
- PIPE-DELIVERY - 5000211363×1
- O-RING - 5000159237×2
- seal - 5000160209×1
- VALVE-CHECK - 5000160391×2
- GASKET - 5000159302×1
- SPACER - 5200009480×1
- SPACE - 5200009490×1
- SPACER - 5200009489×1
- SPACER - 5200009488×1
- SPACER - 5200009487×1
- SPACER - 5200009486×1
- SPACER - 5200009485×1
- Spacer - 5200009484×1
- SPACER - 5200009482×1
- SPACER - 5200009481×1
- SPACER - 5000159278×2
- JET-NOZZLE - 5000155710×2
- O-RING 25 X 12 X 1.78 - 5000159238×2
- SPRING - 5200009491×2
- GASKET - 5200009492×2
- RING 20 X 35 X 1.78 - 5000159236×2
- SCREW M4 X 12 - 5000159471×4
- spring - 5000159317×2
- 335200015521Not stockedCamshaft×1
- Sleeve - 5000215482×1
- Cam - 5000215497×1
- Injector cam - 5000160753×1
- Screw - 5000215540×1
- PIN-LEVER - 5000159321×1
- O-RING - 5000159229×1
- Sleeve - 5000215480×1
- Spring - 5100008864×1
- PLATE - 5200009512×1
- Washer - 5000215520×2
- SCREW M3 X .5 X 6 - 5000159477×6
- 455000160220Not stockedPlate×2
- spring - 5000159315×1
- SCREW M3 X 10 - 5000211941×4
- 485200015528Not stockedLinkage×1
- SCREW - 5200009515×3
- O-RING - 5000159235×1
- plate - 5000159324×1
- SEAL-LIP - 5000159240×1
- BEARING-BALL - 5000159267×1
- SCREW - 5200009514×3
- COVER-GOVERNOR - 5000159265×1
- sleeve - 5000159251×1
- WASHER-THRUST - 5000215517×1
- GOVERNOR-SPEED - 5000155698×1
- SLEEVE CONTROL - 5000215506×1
- BEARING - 5200009517×1
