PT6LT(I)-PUMP W/TRAILER,T4, EU
PT6LT(I) Belt cpl. Diagram
- PULLEY,1 GROOVE,D=85,H 38.4 - 5000215727×1
- BOLT M16 X 1.5 - 5000126935×1
- BOLT M8 X 1.25 X 90 - 5000159490×1
- washer - 5000159346×1
- PULLEY-FAN - 5000155718×1
- washer - 5000159347×1
- Bearing - 5000082135×2
- retaining ring - 5000159241×2
- SPACER - 5000159277×1
- PIN-PILOT - 5000159489×1
- BELT - 5000215699×1
- SCREW M8 X 35 - 5000083026×3
- BRACKET-FAN - 5000159448×1
- SCREW M6 X 1 X 40 - 5000159475×4
- screw - 5000159481×1
- washer - 5000159349×1
- NUT M10 - 5000083011×1
- washer - 5000159344×1
- STUD - 5000159334×1
- PULLEY-JOCKEY - 5000159284×1
- BELT-TIMING - 5000155697×1
- PULLEY-DRIVE - 5000159336×1
- PULLEY-DRIVE W/KEY - 5000159338×1
- SCREW M6 X 1 X 30 - 5000159564×1
- screw M6x35 - 5000160362×4
- GUARD-BELT - 5000155716×1
- plug - 5000159268×1
