PT6LT(I)-PUMP W/TRAILER,T4, EU
PT6LT(I) Air Cleaner/Exhaust System/Manifolds Diagram
- WASHER - 5200009524×1
- BOLT - 5200009525×1
- CONNECTOR - 5000203352×1
- lever - 5000160214×1
- PIN - Throttle - 5200009526×1
- O-RING - 5000159230×1
- SCREW M8 X 35 - 5000083026×2
- SCREW M8 X 65 - 5000084170×9
- LEVER-INTERNAL - 5000215504×1
- Sleeve - 5000215481×1
- Spring - 5000215508×1
- nut - 5000159272×2
- Screw - 5000206214×2
- hose - 5000159462×1
- Nut - 5000084232×1
- 235200015534Not stockedBracket×1
- 235200015535Not stockedBracket×1
- GASKET-INL. MANIFOLD - 5000211368×1
- 255200015536Not stockedAir cleaner cover×1
- 265200015537Not stockedAir cleaner cartridge×1
- PLATE - 5200009528×1
- PIPE-UNION M10 X 1 H-36 - 5000160229×1
- INDICATOR-CLOGGING - 5000155680×1
- GASKET-MANIFOLD - 5000159290×4
- MANIFOLD-EXHAUST W/FRNT OUTLET - 5000211366×1
- STUD M8 X 55 (67) - 5000082267×8
- NUT-COPPER - 5000086331×8
- GASKET-MUFFLER - 5000159295×1
- SCREW M8 X 16 - 5000084156×2
- WASHER - 5000082288×2
- Bracket - 5000215731×1
- STUD M8 X 22 - 5000160228×2
- NUT-COPPER - 5000086331×2
- MUFFLER-EXHAUSTING - 5000155683×1
- Washer - 5000082292×2
- GUARD-MUFFLER - 5000155684×1
- WASHER - 5000082288×3
- Washer - 5000082292×3
- PLUG - 5000084124×3
- PIPE-EXHAUST END - 5000126930×1
- NUT M8 - 5000082140×1
- WASHER - 5000082288×1
- SCREW M8 X 20 - 5000203342×1
- WASHER 8MM - 5200002700×1
