PT6LT(I)-PUMP W/TRAILER,T4, EU
PT6LT(I) Crankcase/Mounts Diagram
- 15200015492Not stockedCrankcase×1
- sleeve - 5000159257×2
- Screw - 5000206229×1
- WASHER-COPPER - 5000082184×1
- Pin - 5000215522×1
- BEARING-SUPPORT (STD) - 5000155702×3
- BEARING-SUPPORT (-0.25) - 5000155703×3
- BEARING-SUPPORT (-0.50) - 5000155704×3
- WASHER .20 - 5000159488×2
- WASHER .10 - 5000159487×2
- WASHER-THRUST - 5000159486×2
- PLUG - 5000082335×6
- GASKET - 5000159288×4
- PIN-DOWEL - 5000159360×2
- screw - 5000159480×10
- plug - 5000159456×1
- 455200015506Not stockedGasket Set×1
- MOUNT-FRONT - 5000160225×1
- MOUNT-REAR - 5000160226×2
- washer - 5000160236×8
- NUT M8 - 5000082140×2
- BOLT M8 X 1, 25 X 20 - 5000160190×8
