PTS4V(I) Pump
PTS4V(I) Cylinder/Crankcase Cover Diagram
- CYLINDER BLOCK ASSY. - 5000118517×1
- Bushing - 5000118519×1
- SEAL-SHAFT - 5000081053×1
- BREATHER ASSEMBLY - 5000160159×1
- Gasket-Breather - 5200002290×1
- SCREW-BREATHER - 5000118451×1
- Tube - 5200001341×1
- GASKET-CRANKCASE COVER - 5000081020×1
- Plug 3/8-18, Sq. Hd. Oil - 5200002531×1
- BEARING-BALL - 5000110082×1
- CRANKCASE CVR W/ OIL PUMP CPL. - 5000227735×1
- SEAL-SHAFT - 5000081018×1
- Screw - 5000208196×1
- Screw - 5000208216×1
- Plate - 5000110083×1
- LEVER-GOVERNOR - 5000118424×1
- O-ring - 5000118433×1
- WASHER - 5000216155×1
- screw - 5000118487×1
- Screw w/washer - 5000118431×1
- Washer - 5000081019×1
- Plug-oil fill - 5200001349×1
- O-ring - 5000118494×1
- O-ring - 5000118439×1
- Screw - 5000160165×1
- Nut - 5000118425×1
- Dipstick - 5000116503×1
- SEAL - DIPSTICK TUBE - 5000116501×1
- TUBE-OIL FILL - 5000116502×1
- BUSHING-CRANK,GOVERNOR - 5000118441×1
- Bolt - 5000118426×1
- Baffle - 5000080981×1
- Screw - 5000118471×1
- PIN-COTTER - 5000118478×1
- YOKE-GOVERNOR CONTROL - 5000080988×1
- Seal-shaft, governor - 5200001345×1
- ADAPTER-OIL FILTER MOUNT - 5000118510×1
- PIN-LOCATING - 5000118435×1
- GASKET-FILTER,OIL - 5000118502×1
- COVER-OIL PUMP - 5000118459×1
- Pump-Oil - 5200001346×1
- BUSHING-CRANK - 5000119790×1
