RD18-100c.3
RD18-100C.3 sprinkling Diagram
- Sprinkler pipe - 5100013167×1
- Sealing ring - 5100011513×2
- Cap - 5100011514×2
- Nozzle holder - 5100011530×4
- Cap nut - 5100011535×4
- Sheet metal screw - 5100011607×4
- Membrane holder - 5100011651×4
- Sealing ring - 5100011752×4
- Membrane - 5100011978×4
- Nut - 5100011488×4
- Filtering screen - 5100011489×4
- Sprinkler nozzle - 5100011529×4
- Half-clip - 5100013469×6
- Cover plate - 5100013465×2
- Cheese-head screw - 5100012052×4
- Bracket - 5100013168×2
- Sprinkler pipe - 5100013169×1
