RD28-120

RD28-120 compactometer Diagram

Exploded parts diagram of the compactometer of a Wacker Neuson RD28-120, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 35100033251Not stocked
    holder system×1
  • 45100012718
    $1.66
    Cheese-head screw - 5100012718×2
  • 55100012936
    $2.27
    Washer - 5100012936×2
  • 65100033252Not stocked
    bushing×2
  • 105100033253Not stocked
    calculator×1
  • 115100033254
    $1.49
    cheese-head screw - 5100033254×2
  • 125100013453
    $1.49
    Washer - 5100013453×2
  • 135100012936
    $2.27
    Washer - 5100012936×2
  • 145100012898
    $3.15
    Hexagon nut - 5100012898×2
  • 165100033255Not stocked
    blade-type fuse×2
  • 165100033256Not stocked
    cable harness×1
  • 185100033257Not stocked
    splash protection×1
  • 205100033258Not stocked
    acceleration sensor×1
  • 415100033259Not stocked
    cable harness×1
  • 505100025103
    $5,335.29
    instrument panel - 5100025103×1
  • 515100025100
    $406.42
    covering part - 5100025100×1
  • 525100011580
    $11.69
    Blind cover - 5100011580×1
