RD28e-120o

RD28-120OE canopies and covers Diagram

Exploded parts diagram of the canopies and covers of a Wacker Neuson RD28-120OE, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15100076298Not stocked
    engine cover×1
  • 25100012498
    $2.62
    Safety screw - 5100012498×4
  • 45100023077
    $11.13
    u-washer - 5100023077×4
  • 55100012193
    $113.70
    Hinge - 5100012193×2
  • 65100012214
    $55.13
    Metal plate - 5100012214×2
  • 95100059939Not stocked
    covering part×1
  • 135100011544
    $6.72
    Clip nut - 5100011544×2
  • 195100012696
    $107.27
    Lock - 5100012696×1
  • 205100012517
    $1.57
    Hexagon screw - 5100012517×4
  • 215100012966
    $1.57
    Locking washer - 5100012966×8
  • 225100012546
    $1.57
    Hexagon nut - 5100012546×4
  • 235100013588
    $261.67
    Lock outside handle - 5100013588×1
  • 245100013590
    $5.50
    Supporting plate - 5100013590×1
  • 255100013589
    $4.48
    Supporting plate - 5100013589×1
  • 265100013404
    $1.57
    Cheese-head screw - 5100013404×2
  • 275100012965
    $3.01
    Locking washer - 5100012965×2
  • 285100050643
    $8.47
    knurled head screw - 5100050643×1
  • 295100012545
    $1.57
    Hexagon nut - 5100012545×1
