RD45-140 Tandem Roller
RD45-140 Driver'S Cabin Diagram
- Cabin door - 5100013281×1
- Hinge pin - 5100013280×2
- 45100013321Not stockedSealing ring×4
- Washer - 5100012939×2
- 65100013417Not stockedSplit pin×2
- Hinge - 5100013284×2
- Hinge - 5100013285×2
- Rubber seal - 5100013291×4
- 115100013316Not stockedDistance bush×4
- Protecting cap - 5100013572×8
- Hexagon screw - 5100013510×4
- Washer - 5100012938×4
- Safety nut - 5100011476×4
- Greasing nipple - 5100013027×4
- Mounting - 5100013299×4
- Side pane - 5100013221×1
- Window lock - 5100013305×1
- Fillister head screw - 5100012866×2
- Washer - 5100012936×2
- Mounting - 5100011603×1
- Closing bolt - 5100011503×1
- Bow - 5100011557×1
- 275100013303Not stockedPlate×1
- Rebound strap - 5100013308×1
- Bracket - 5100013309×2
- Countersunk screw - 5100012595×4
- gas spring - 5100024989×1
- Sealing profile - 5100013443×5
- Edge protection - 5100013419×9.5
- Tools - 5100013307×1
