RD45-140 C Tandem Roller

RD45-140C additional mirror Diagram

Exploded parts diagram of the additional mirror of a Wacker Neuson RD45-140C, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 205100012897Not stocked
    Metal plate×1
  • 215100053249
    $1.49
    hexagon screw - 5100053249×2
  • 225100012966
    $1.57
    Locking washer - 5100012966×4
  • 235100059489Not stocked
    distance piece×2
  • 245100013257
    $1.57
    Washer - 5100013257×2
  • 255100012546
    $1.57
    Hexagon nut - 5100012546×2
  • 305100067838
    $176.46
    stay bar - 5100067838×1
  • 315100012613
    $1.57
    Hexagon screw - 5100012613×2
  • 325100012966
    $1.57
    Locking washer - 5100012966×2
  • 355100067837Not stocked
    stay bar×1
  • 365100012613
    $1.57
    Hexagon screw - 5100012613×2
  • 375100012966
    $1.57
    Locking washer - 5100012966×2
  • 405100067839
    $83.58
    mirror - 5100067839×2
