RTLx-SC3 TRENCH ROLLER,ORG/GY
RTLX-SC3 Piston/Connecting Rod Diagram
- SET-PISTON +1.00 - 5000160377×3
- SET-PISTON (STD) - 5000160375×3
- SET-PISTON +.50 - 5000160376×3
- CONNECTING ROD - 5200009449×3
- RINGS STD. - 5000160383×2
- RINGS +.50 - 5000160384×2
- RINGS +1.00 - 5000160385×2
- Pin - 5000215523×3
- CLIP - 5000215477×6
- BUSHING-SMALL END - 5200009452×2
- BUSHING-BIG END (-0.50) - 5000155691×2
- BUSHING-BIG END (STD.) - 5000155689×2
- BUSHING-BIG END (-0.25) - 5000155690×2
- Screw - 5000084175×4
