SPARE PARTS LIST 1302RD Primus SP

1302RDPRIMUS VALVE ANGLE Diagram

Exploded parts diagram of the VALVE ANGLE of a Wacker Neuson 1302RDPRIMUS, with numbered balloons — Hover a box for the part, its price and its row below. Click it to select.

11000065563Not stocked
mounting×1
21000065564Not stocked
mounting×1
31000083210Not stocked
bushing×4
41000065566Not stocked
locking×1
51000065565Not stocked
locking lever×1
61000364347Not stocked
thread rod×8
71000015428Not stocked
ball button×1
81000015373Not stocked
countersunk screw×4
91000015374Not stocked
thread pin×2
101000083334
$3.11
fork head - 1000083334×2
111000013021Not stocked
hexagon nut×2
121000015431Not stocked
washer×1
131000015437Not stocked
lock washer×1
141000065569Not stocked
thread rod×1
151000013021Not stocked
hexagon nut×2
161000083334
$3.11
fork head - 1000083334×1
171000015635
$20.00
BALL AND SOCKET - 1000015635×1
181000065561Not stocked
hammer pedal×1
191000065559Not stocked
hammer pedal×1
201000065562Not stocked
cross control plate×2
211000015635
$20.00
BALL AND SOCKET - 1000015635×6
221000013014Not stocked
cheese head screw×1
231000015437Not stocked
lock washer×8
241000065570Not stocked
control lever×2
251000015415Not stocked
hexagon nut×2
261000082596Not stocked
ball button×2
271000003047Not stocked
bellow×2
281000082718
$0.74
cotter pin - 1000082718×1
291000085468
$0.42
cheese head screw M10x25-8.8 A2C-DIN912 - 1000085468×4
301000065567Not stocked
shift lever×1
311000065568Not stocked
shift lever×1
321000015346Not stocked
hex screw×2
331000015438Not stocked
lock washer×2
341000015407Not stocked
hexagon nut×2
351000019658
$5.99
HANDLE - 1000019658×2
361000015089
$90.00
bellow - 1000015089×2
371000015340Not stocked
hex screw×4
381000015627Not stocked
cover plate×2
391000015632Not stocked
clamp body×2
401000015432
$0.05
washer 10,5 A2C DIN125 - 1000015432×4
411000015438Not stocked
lock washer×4
