AR34/6/042
AR34/6/042 External Vibrator cpl. Diagram
- 5000010618$0.28WASHER B17 FLAT - 5000010618×1
- Motore Armature - 5100001545×1
- 35100001549Not stockedBearing bracket×2
- Shim 21x27x0,4 - 5100002170×1
- Grooved ball bearing 6304 - 5100002152×2
- WEIGHT - 5000127791×32
- 75000033351Not stockedHexagon nut×2
- Bonnet short - 5100001529×2
- O-ring 89,00x2,50 - 5100002201×2
- Washer - 5000209458×3
- NUT M4 8,HEX. - 5000010872×3
- Gasket - 5100001541×1
- Cover - 5100001542×1
- Clamp - 5000106220×1
- Label - 5000219173×1
- screw connection - 5100002084×1
- Cable bushing - 5100042134×1
- SCREW M5 X 12 SOC.HD. - 5000095509×12
