ARFU26/6/120 US

ARFU26/6/120US External Vibrator cpl. Diagram

Exploded parts diagram of the External Vibrator cpl. of a Wacker Neuson ARFU26/6/120US, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15100005191
    $1,417.27
    Ext. Vib. ARFU cpl. - 5100005191×1
  • 25100003121
    $128.84
    Motor armature cpl. - 5100003121×1
  • 35100003631
    $0.66
    Shim 15,8x21,8x0,2 - 5100003631×1
  • 45100004449
    $10.22
    Grooved ball bearing 6302 - 5100004449×2
  • 55100003117
    $115.71
    Bearing bracket - 5100003117×2
  • 65000033351Not stocked
    Hexagon nut×4
  • 75000127791
    $4.64
    WEIGHT - 5000127791×16
  • 95100002201
    $4.38
    O-ring 89,00x2,50 - 5100002201×2
  • 105100001529
    $29.98
    Bonnet short - 5100001529×2
  • 115000095509
    $0.31
    SCREW M5 X 12 SOC.HD. - 5000095509×8
  • 135100042134
    $8.31
    Cable bushing - 5100042134×1
  • 145100002084
    $7.33
    screw connection - 5100002084×1
  • 155000106220
    $1.79
    Clamp - 5000106220×1
  • 165000209458
    $0.10
    Washer - 5000209458×3
  • 175000010872
    $0.01
    NUT M4 8,HEX. - 5000010872×3
  • 185100003596
    $9.06
    Gasket - 5100003596×1
  • 195100003534
    $74.43
    Cover - 5100003534×1
  • 205000200931
    $0.18
    SCREW-COUNTERSUNK - 5000200931×4
  • 225000219173
    $10.45
    Label - 5000219173×1
  • 265100060422
    $81.31
    Supply line - 5100060422×1
  • 295100042029Not stocked
    Spacer×1
