BS50-4As 11IN
BS50-4AS Cylinder Block Diagram
- 15200018716Not stockedCover×1
- CAP ASSY-OIL FILLER - 5000217161×1
- Gasket - 5000162647×1
- GOVERNOR COMPLETE - 5000162152×1
- SLIDER - 5000070953×1
- Shaft-governor - 5000162153×1
- SCREW M6 X 25, FLANGED - 5000081737×8
- PLUG - 5000070964×1
- Washer - 5000070959×1
- Washer - 5000070963×1
- RET.RING 7.7MM,FORM C - 5000081615×1
- SEAL-SHAFT - 5000162142×1
- 185200015335Not stockedOil seal×1
- WASHER 6MM,PLAIN - 5000071639×2
- PIN - 5000054033×1
- PIN-DOWEL,A8 X 20 - 5000162155×2
- BEARING-BALL - 5000162157×1
