BS60-4As Vibratory Rammer, 11" Plastic Shoe

BS60-4AS Muffler Diagram

Exploded parts diagram of the Muffler of a Wacker Neuson BS60-4AS, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15200015309Not stocked
    Muffler×1
  • 25200018699Not stocked
    Muffler cover×1
  • 65000162104
    $12.27
    Gasket - 5000162104×1
  • 95000152487
    $3.52
    BOLT-FLANGE 6X14 - 5000152487×3
  • 105200015312Not stocked
    Stud bolt×2
  • 125200015313Not stocked
    Nut×2
