CRT36-25
CRT36-25 Intake/Exhaust Diagram
- CAMSHAFT - 5200009851×1
- Tappet - 5000215181×4
- SPRING-VALVE - 5000205607×4
- RETAINER-SPRING - 5000205608×4
- VALVE-INTAKE - 5000205609×2
- VALVE-EXHAUST - 5200009853×2
- VALVE COLLET - 5000205611×8
- ROD-PUSH - 5200009854×4
- Rocker Arm - 5000215243×4
- BOLT-PIVOT - 5000215865×4
- PIVOT - 5000205618×4
- nut - 5000205619×4
- GUIDE PLATE - 5200009856×2
- MANIFOLD-INTAKE - 5200009857×1
- STUD - 5200009858×4
- NUT M6,HEX,FLANGE - 5000053616×4
- AIR CLEANER CPL - 5200009865×1
- AIR CLEANER BASE COMPLETE - 5200009866×1
- COVER-AIR CLEANER - 5000215179×1
- NUT-WING - 5000215180×1
- ELEMENT-AIR CLEANER - 5000215117×1
- GASKET-AIR CLEANER - 5200009859×1
- GASKET - 5200009860×1
- GASKET-CARBURETOR - 5200009861×1
- GASKET-INTAKE MANIFOLD - 5000215183×2
- NUT-FLANGE - 5000215261×3
- NUT-FLANGE - 5000075270×4
- ADAPTER - 5200009862×1
- BREATHER TUBE - 5200009863×1
- CLAMP-HOSE - 5000215235×2
- CAP-VINYL - 5200009864×1
