CRT48-57K Trowel, Power Steer

CRT48-57K-PS Panel cpl. Diagram

Exploded parts diagram of the Panel cpl. of a Wacker Neuson CRT48-57K-PS, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 35200023465Not stocked
    Upper frame×1
  • 45000164099Not stocked
    Front panel×1
  • 55200024716Not stocked
    Foot plate cpl.×1
  • 65200024411Not stocked
    Plate×1
  • 75000179110Not stocked
    Bracket×1
  • 105000164103Not stocked
    Step plate×1
  • 165200023455Not stocked
    Left side panel×1
  • 175200023453Not stocked
    Right side panel×1
  • 255000165031Not stocked
    Plate×1
  • 325000155125Not stocked
    Stud×2
  • 1295000178304Not stocked
    Controller module×1
  • 2045200024607Not stocked
    Pedal lever cpl.×1
  • 2345000164908Not stocked
    Splash guard×1
  • 4065000028949Not stocked
    Hexagonal flange head screw×32
  • 4165000012362Not stocked
    Hexagonal head cap screw×2
  • 4355000079363Not stocked
    Screw×10
  • 4465000011477Not stocked
    Hexagonal head cap screw×1
  • 4475000011439Not stocked
    Hexagonal head cap screw×8
  • 4515000095917Not stocked
    Cheese head screw×2
  • 4525000010368Not stocked
    Hexagon nut×6
  • 4535000029117Not stocked
    Lock nut×6
  • 4545000010367Not stocked
    Hexagon nut×2
  • 4595000089316Not stocked
    Lock nut×8
  • 4605000030066Not stocked
    Locknut×4
  • 4705000150959Not stocked
    Clip nut×13
  • 4815000010621Not stocked
    Flat washer×8
  • 4825000010625Not stocked
    Flat washer×1
  • 6555200024413Not stocked
    Cover×1
  • 6565000192831Not stocked
    Latch×1
  • 6575000011474Not stocked
    Hexagonal head cap screw×1
  • 6775200025746Not stocked
    Guard×1
  • 10055200019287Not stocked
    Diagnostic cable×1
