CT24-230E TROWEL,EU
CT24-230EEU Blade Mechanism Diagram
- Gearbox - 5000174231×1
- Yoke - 5000174148×1
- BRACKET-YOKE - 5000174927×2
- Bolt - 5000174925×2
- Clip - 5000174928×2
- SHAFT-YOKE - 5000174930×1
- Key - 5000174931×1
- PLATE-THRUST BEARING - 5000174933×1
- Retaining ring - 5000174934×1
- Bearing - 5000174935×1
- Bearing - 5000174936×1
- Bearing - 5000174937×1
- BELT-EDGE GUARD - 5000174938×1
- GUARD-SPINNING RING - 5000174939×1
- SHAFT-GEARBOX - 5000174940×1
- Retaining Ring - 5000174941×1
- PLATE-PRESSURE - 5000174942×1
- RING-STABILIZER - 5000174943×1
- HUB-SPIDER - 5000174944×1
- SCREW-SPIDER - 5000174945×4
- LEVER-LIFT - 5000174946×4
- BOLT-LIFT LEVER - 5000174947×4
- NUT 62 - 5000174948×8
- BOLT-CARRIAGE,63 - 5000174949×4
- MOUNT-BLADE - 5000174950×4
- Bolt - 5000174951×8
- SET-FINISH BLADES,4 PER,CT24 - 5000174106×4
- BOLT-SPECIAL - 5000174953×4
- SCREW-FLAT HEAD - 5000174954×4
- WASHER-SPIDER,RETAINING - 5000174955×1
- SCREW-FLAT HEAD - 5000174894×1
- FITTING-GREASE - 5000174956×4
- BLADE-PAN,24 - 5000174107×1
- Key - 5000176685×1
- KEY - 5000175036×1
- Key - 5000176687×1
