CT48-13A-V Trowel

CT48-13A-V Camshaft cpl. Diagram

Exploded parts diagram of the Camshaft cpl. of a Wacker Neuson CT48-13A-V, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15000151750
    $10.09
    SEAL-VALVE STEM - 5000151750×1
  • 25100000378
    $97.45
    Camshaft cpl. - 5100000378×1
  • 45200001633Not stocked
    Push rod (valve lifter)×2
  • 55000074675
    $10.99
    ROCKER ARM-VALVE - 5000074675×2
  • 65000074678
    $20.23
    valve tappet - 5000074678×2
  • 75000070985
    $7.60
    PIVOT-ROCKER ARM - 5000070985×1
  • 85000151028
    $3.98
    SPRING-WEIGHT RETURN - 5000151028×1
  • 95200000493
    $10.89
    Valve-intake - 5200000493×1
  • 105200000494
    $15.08
    Valve-exhaust - 5200000494×2
  • 115000217481
    $6.99
    Spring - 5000217481×2
  • 125200000495
    $2.82
    Holder-spring - 5200000495×1
  • 135000074659
    $4.53
    SEAT-VALVE SPRING - 5000074659×1
  • 145000074659
    $4.53
    SEAT-VALVE SPRING - 5000074659×1
  • 165200000543
    $1.09
    Plate - 5200000543×1
  • 185000072778
    $10.09
    STUD-ROCKER ARM PIVOT - 5000072778×2
  • 195000070984
    $4.97
    NUT 1/4-28,PIVOT ADJUSTMENT - 5000070984×2
