DPS3060-VIBROPLATE
DPS3060 Crank Holder cpl. Diagram
- SCREW M8 X 60 HX.HD. - 5000011345×1
- WASHER B8.4 FLAT - 5000010374×2
- SCREW M8 X 25 SOC.HD. - 5000011542×2
- NUT-LOCK M8 HEX - 5000010367×1
- COUPLING-FLEX 27X45X40,FORM S - 5000058341×1
- LEVER - 5000099862×1
- ANGLE COMPLETE - 5000058337×1
- WASHER-LOCK 10 - 5000033988×1
- SCREW M10 X 20 SOC.HD. - 5000011536×1
- WASHER-FLAT,M8,ZINC - 5000010622×8
- Plate - 5000058339×1
- PIN 6 X 14 GROOVED - 5000020334×1
- Guide - 5000058338×1
