Vibration Plate DPU6260H

DPU6260H Baseplate basis Diagram

Exploded parts diagram of the Baseplate basis of a Wacker Neuson DPU6260H, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 105100046191Not stocked
    Hose pipe×1
  • 115000014425
    $2.06
    SCREW M6 X 8 SOC.HD. - 5000014425×1
  • 125100022402
    $0.88
    Gasket A- 6,0x12,0 - 5100022402×1
  • 205100047663Not stocked
    O-ring×1
  • 305100057493Not stocked
    O-ring×1
  • 405100018059
    $2.52
    corrugated-head screw M12x 25 - 5100018059×8
  • 505100047185Not stocked
    Seal ring×1
  • 605000014535
    $6.99
    PLUG M16 X 1.5 ST - 5000014535×1
  • 705000012373
    $0.26
    SCREW M6 X 22 SOC.HD. - 5000012373×4
  • 805002004814
    $74.83
    SHOCKMOUNT 100 X 58-45SH,FRM C - 5002004814×4
  • 905000216644
    $18.65
    Shockmount - 5000216644×4
