DPU 7060Fe

DPU7060FE Upper Mass cpl. Diagram

Exploded parts diagram of the Upper Mass cpl. of a Wacker Neuson DPU7060FE, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15000013565
    $2.04
    SCREW M10 X 65 SOC.HD - 5000013565×8
  • 25000201546
    $648.08
    FAN-COWL - 5000201546×1
  • 35000011552
    $0.22
    SCREW M6 X 18 SOC.HD. - 5000011552×2
  • 45000010624
    $0.03
    WASHER B6.4 FLAT - 5000010624×2
  • 55000201544
    $133.78
    base plate - 5000201544×1
  • 65000102208Not stocked
    Coupling cpl.×1
  • 75000011528
    $0.92
    SCREW M12 X 35 SOC.HD. - 5000011528×1
  • 85000011535
    $0.59
    SCREW M10 X 25 SOC.HD. - 5000011535×4
  • 95000058855Not stocked
    Clutch flange×1
  • 105000220329
    $10,889.41
    Engine 5000220329×1
  • 115000049059
    $0.35
    NUT M12 X 1.75,FLANGED - 5000049059×4
  • 125000201889
    $5.89
    CLAMP-HOSE - 5000201889×1
  • 135000201892
    $158.44
    FILTER-CYCLON - 5000201892×1
  • 145000201995
    $144.65
    Pipe band - 5000201995×1
  • 155000049158
    $3.76
    STUD-THREADED - 5000049158×1
  • 165000010884
    $0.26
    NUT M12 8,HEX - 5000010884×1
  • 175000021465
    $2.70
    WASHER-LOCK HS12,HIGH TENSION - 5000021465×4
  • 185000011304
    $0.76
    SCREW M12 X 65 HX.HD. - 5000011304×3
  • 195000094035
    $17.06
    HOSE - 5000094035×1
  • 205000019141Not stocked
    Hexagon nut×2
  • 215000203543
    $4.85
    CLAMP - 5000203543×1
  • 225000011534
    $0.94
    SCREW M10 X 30 SOC.HD. - 5000011534×1
  • 235000058547
    $127.35
    PLATE-CLUTCH FACE - 5000058547×1
  • 245000048374
    $16.62
    SPRING-BELLEVILLE TYPE - 5000048374×2
  • 255000048273
    $10.45
    GASKET-RUBBER - 5000048273×1
  • 265000058546
    $68.09
    DISC-CENTRIFUGAL CLUTCH - 5000058546×1
  • 275000021147
    $1.06
    RET.RING-INT 60MMX2MM, - 5000021147×1
