DPU80Lem770
DPU80LEM770 Tank - Radiator DPU80/90 Diagram
- Hydraulic Tank - 5100005488×1
- Filter Element - 5100010301×1
- Filter Element - 5100010303×1
- Return filter - 5100010302×1
- SCREW M8 X 22 SOC.HD. - 5000012629×2
- Electric Fan - 5100010341×1
- Hexagonal head cap screw M 5x 12 - 5100015757×4
- Gasket - 5100016476×1
- Gasket - 5100016478×1
- Plate - 5100015887×1
- Radiator - 5100005489×1
- SCREW-CORRUGATED HD. - 5000211795×5
- Bracket - 5100014130×1
- Cable passage - 5100010830×2
- WASHER-FLAT,M8,ZINC - 5000010622×2
- SCREW M8 X 12 HX.HD. - 5000012360×2
- Bolted connection L18-LK35 - 5100010161×1
- SCREW M6 X 35 SOC.HD. - 5000011548×2
- SCREW M6 X 16 SOC.HD. - 5000011553×2
- Screwed socket L18 G3/4 - 5100011096×1
- Hose pipe - 5100010252×1
- bleeder bottle - 5100009849×1
- WASHER B8.4 FLAT - 5000010374×2
- SCREW M8 X 30 HX.HD. - 5000011456×2
- Cover - 5100015982×1
- radiator hose - 5100015647×1
- Water Hose - 5100010313×1
- Water Hose - 5100006059×1
- 295002004724Not stockedWorm drive house clip×4
- Hose pipe cpl. - 5100010256×1
- 315000016836Not stockedClamp×1
- CLAMP - 5000206551×1
- WASHER B6.4 FLAT - 5000010624×1
- Bracket - 5100010567×1
- Bracket - 5100010568×1
- PIN-ROLL - 5000097656×1
- Shockmount - 5100009991×2
- hammer head bolt M 8x100 - 5100015096×2
- NUT M8 8,HEX - 5000010882×2
- Gasket - 5100016491×1
- Gasket - 5100016492×1
- VIEW GLASS - 1000262373×1
- Cover (bayonet lock) - 5100011421×1
- Plug (threaded) M18x 1,5 - 5100015762×1
- FITTING-PIPE L18R - 5000063739×1
- Screw - 5000211755×1
