DW20-2
DW20-2 CYLINDER HEAD, VALVE COVER Diagram
- PROTECTION - 1000148750×3
- SEAL RING - 1000002938×6
- valve cap - 1000148761×6
- Cylinderhead 1000148763×1
- PLUG - 1000148764×2
- Plug - 1000312566×1
- intake valve - 1000148765×3
- outlet valve - 1000148766×3
- SPRING - 1000148767×6
- WASHER - 1000143728×6
- CLAMP - 1000143749×12
- SEAL - 1000143729×3
- SEAL - 1000143731×3
- COTTER PIN - 1000107509×2
- SHAFT - 1000148768×1
- HEX SCREW - 1000085180×3
- 341000002921Not stockedoil filler cap×1
- Valvecover 1000148762×1
- PLATE - 1000312569×1
- PLATE - 1000312568×1
- PLATE - 1000312568×2
- DIAPHRAGM - 1000148769×1
- PLATE - 1000107527×1
- Cover - 1000178891×1
- Spring - 1000178892×1
- VALVE COVER SEAL - 1000148554×1
- box cover - 1000312564×1
- Seal - 1000148851×1
- 481000107523Not stockedscrew×4
- 491000107523Not stockedscrew×4
- SCREW - 1000185005×2
- 511000035757Not stockedseal ring×1
- Screw - 1000035840×3
- hex screw - 1000312563×6
- JOINT - 1000107504×1
- HEX SCREW - 1000085176×2
- glow pin - 1000148770×3
- cable - 1000148771×1
- valve guide - 1000143733×6
