DW20-2

DW20-2 Engine attachments parts Diagram

Exploded parts diagram of the Engine attachments parts of a Wacker Neuson DW20-2, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000375429Not stocked
    fixing plate×1
  • 21000423000
    $59.80
    plate - 1000423000×1
  • 31000377417Not stocked
    sensor×1
  • 41000085382
    $0.70
    HEX SCREW - 1000085382×1
  • 51000390126Not stocked
    bushing housing×1
  • 61000224648
    $1.87
    Ring - 1000224648×1
  • 71000019136Not stocked
    hex screw×1
  • 81000015448Not stocked
    washer×1
  • 91000013009Not stocked
    hex screw×2
  • 101000094974
    $0.70
    washer M10-DIN134 - 1000094974×2
  • 111000375997Not stocked
    fixing bracket×2
  • 121000322839Not stocked
    fixing bracket×1
  • 131000015430Not stocked
    u-washer×1
  • 141000268492
    $62.17
    temperature sensor 3503, EZ53 - 1000268492×1
  • 151000357533Not stocked
    hexagon nut×1
