DW20-2

DW20-2 combicooler Diagram

Exploded parts diagram of the combicooler of a Wacker Neuson DW20-2, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000381290
    $1,996.35
    combicooler - 1000381290×1
  • 21000496220
    $306.14
    Radiator scoop - 1000496220×1
  • 31000381264Not stocked
    water hose×1
  • 41000381265Not stocked
    water hose×1
  • 51000004819Not stocked
    swing metal buffer×4
  • 61000098164
    $21.58
    rubber profile 1,5-3mm - 1000098164×1.1
  • 71000017845Not stocked
    rubber profile×2.1
  • 81000384546
    $215.02
    plate - 1000384546×1
  • 91000384308
    $150.40
    bracket - 1000384308×1
  • 101000082979
    $6.95
    GE18LR1/2EDOMDA3C - 1000082979×2
  • 111000375983Not stocked
    cooler cap×1
  • 121000273882
    $20.27
    view glass G3/4" - 1000273882×1
  • 131000015431Not stocked
    washer×9
  • 141000013008Not stocked
    hex screw×6
  • 151000426230Not stocked
    lock washer×2
  • 161000013009Not stocked
    hex screw×2
  • 171000085411
    $1.37
    hex screw M10x20-8.8 A2C DIN933 - 1000085411×2
  • 181000019136Not stocked
    hex screw×3
  • 191000015432
    $0.05
    washer 10,5 A2C DIN125 - 1000015432×2
  • 201000092303
    $0.86
    Washer 10,5 St A2C - 1000092303×4
  • 211000357534Not stocked
    hexagon nut×4
  • 221000090083
    $2.13
    Cable strap T80IFT6 - 1000090083×5
  • 231000067377Not stocked
    hose clamp×4
  • 241000015434Not stocked
    washer×2
  • 251000357535Not stocked
    hexagon nut×2
  • 261000082786
    $3.66
    VSTI1/2EDA3C - 1000082786×1
  • 271000293439Not stocked
    clip×1
