FU 1,5/200 W

FU1,5/200W Converter cpl. Diagram

Exploded parts diagram of the Converter cpl. of a Wacker Neuson FU1,5/200W, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15000105094Not stocked
    Fan cowl×1
  • 25000105095Not stocked
    Fan×1
  • 35000105096Not stocked
    Bearing bracket×1
  • 45000107197Not stocked
    Stator stack×1
  • 55000105099Not stocked
    Washer×1
  • 65002006705
    $19.20
    BEARING-RADIAL BALL,6205 - 5002006705×2
  • 75000125020Not stocked
    Rotor×1
  • 85000107198Not stocked
    Stator stack×1
  • 95000219675Not stocked
    L-Profile×2
  • 105000011561
    $0.22
    SCREW M5X16-8.8VZ,SOC.HD.CAP - 5000011561×1
  • 115000011550
    $0.09
    SCREW M6 X 25 SOC.HD. - 5000011550×1
  • 125000010368
    $0.10
    NUT-LOCK M6 HEX. - 5000010368×4
  • 135000105097Not stocked
    Pulling bolt×4
  • 145000010649
    $0.07
    WASHER-LOCK B6 - 5000010649×4
  • 155000010880
    $0.03
    NUT M6 8,HEX - 5000010880×4
  • 165000013620
    $0.10
    SCREW B4.2 X 9.5 XREC - 5000013620×2
  • 175000211716Not stocked
    Bearing bracket×1
