G25 switchable 600 VOLT T4i GENERATOR, COLD WEATHER
G25 Voltage Selector Switch Box Diagram
- PANEL-SS BOX BOTTOM,SMALL P-5000176420 - 5000181222×1
- PANEL,SS BOX TOP P-5000176420 - 5000157933×1
- BRACKET-SS REAR,SMALL P-5000176420 - 5000181224×1
- STRAP-GROUND 10 - 5000152978×1
- TERMINAL BOARD - 5000183343×2
- TRANSFORMER-CURRENT,100:5A - 5000153231×3
- 4755200017210Not stockedPhase switch×1
- 4805200018200Not stockedTransformer×3
- HOLDER-FUSE,CLASS CC - 5000154771×1
- 4825200018201Not stockedFuse×3
- CLAMP-P,0.25 DIA - 5000181214×2
- INSULATOR-REAR,CONTROL PANEL - 5000164228×1
- 7015200018966Not stockedLabel-sheet×1
- 7155200018777Not stockedLabel×1
- SCREW M4 X 20 PHIL HD - 5000110951×4
- SCREW M4 X 14 PHIL HD - 5000110405×4
- SCREW M6 X 16,HX.HD,SER.FLG - 5000028949×13
- SCREW M6 X 10 HX.HD. - 5000012356×4
- SCREW M6 X 10,HX.HD,SER.FLG - 5000073164×10
- SCREW M6 X 20 SOC.HD. - 5000011551×4
- NUT-LOCK M4 HEX. - 5000010370×8
- NUT-LOCK M6 HEX. - 5000010368×13
- Nut M8 Flange, Non serrated - 5000115570×1
- WASHER A4.3 FLAT - 5000010628×12
- WASHER B6.4 FLAT - 5000010624×4
- 10005200018360Not stockedLocking device×1
- 10015200018361Not stockedPlate×1
- 10025200018362Not stockedHandle×1
- TERMINAL BLOCK - 5200003951×2
