GPi4300

GPI4300 Oil Sensor Diagram

Exploded parts diagram of the Oil Sensor of a Wacker Neuson GPI4300, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 105000226371
    $336.16
    Flywheel cpl. - 5000226371×1
  • 115000156643
    $189.49
    COIL-IGNITION COMPLETE - 5000156643×1
  • 305000156107
    $0.69
    BOLT W/WASHER - 5000156107×2
  • 505000205502
    $9.75
    WIRE - 5000205502×1
  • 1005000156554
    $19.75
    SPARK PLUG,NGK-R,BR6HS - 5000156554×1
  • 1105000156555
    $10.77
    CAP-SPARK PLUG - 5000156555×1
  • 7005200001485Not stocked
    Oil sensor switch×1
  • 7405000156558
    $1.49
    BOLT W/WASHER - 5000156558×1
  • 7715000205507
    $0.85
    screw - 5000205507×1
  • 7745000205506
    $5.28
    CLAMP-WIRE - 5000205506×1
