GPS9700V Generator, EPA, w/Wheel Kit
GPS9700 Carburetor Diagram
- GASKET-CARBURETOR MOUNT - 5000080903×1
- Kit-Idle Mixture - 5200002295×1
- Screw - 5000118446×1
- SHAFT-THROTTLE - 5000116550×1
- SCREW-IDLE SPEED - 5000116537×1
- GASKET-INTAKE ELBOW - 5000079783×1
- PIN-FLOAT HINGE - 5000080895×1
- Valve-float needle - 5200001355×1
- Valve-choke - 5200001356×1
- X-5000208205 SHAFT-CHOKE - 5200002296×1
- JET-MAIN - 5200002297×1
- Screw - 5000080894×4
- CARBURETOR - 5200002300×1
- VALVE-THROTTLE - 5000116525×1
- Float-carburetor - 5200002301×1
- Screw - 5000118446×2
- RING-COLLAR,CHOKE CONTROL - 5000080798×1
- GASKET - 5000080908×1
- Seal - 5000080799×1
- PLUG - 5000080907×1
- CAP-LIMITER - 5200002317×1
- SEAL-SHAFT - 5000116524×1
