Oil-fired space heater with chimney
HI90 Fire-place heater Diagram
- 15000227868Not stockedRing×1
- 25000227863Not stockedChimney×1
- 35000227884Not stockedCover plate×1
- 45000227886Not stockedCombustion chamber×1
- 55000227870Not stockedCover×1
- 65000227872Not stockedCover inspection×1
- 75000227888Not stockedLower part×1
- 85000227822Not stockedEngine complete×1
- 95000227829Not stockedCapacitor×1
- 105000227874Not stockedFlange×1
- 115000227971Not stockedVentilator×1
- 125000211220Not stockedScreen grid×1
- 135000227949Not stockedTube×1
- 145000227935Not stockedConnector×2
- 155000211255Not stockedOil filter×1
- 165000211260Not stockedGasket Set×1
- 175000211256Not stockedFilter Element×1
- 185000211258Not stockedFilter housing×1
- 195000229063Not stockedSupport×1
- 205000227948Not stockedTube×2
- 215000227959Not stockedHandle×1
- 225000229055Not stockedShock absorber×4
- 235000227960Not stockedFoot×1
- 245000227950Not stockedTube×1
- 255000227939Not stockedIntake pipe×1
- 265000227941Not stockedConnector×1
- 275000229062Not stockedHook×1
- 285000227875Not stockedTank×1
- 295000210704Not stockedFuel tank cap×1
- 305000229068Not stockedAxle×1
- 315000229064Not stockedClamp×2
- 325000210690Not stockedWheel×2
- 335000227952Not stockedDistance ring×2
- 345000227956Not stockedSplit×2
- 355000227938Not stockedPlug (threaded)×1
- 365000227810Not stockedO-Ring×1
- 375100003086Not stockedSwitch box×1
- 385000210866Not stockedBaffle×2
- 395000227967Not stockedCovering×1
- 405000227889Not stockedBox×1
- 415000210699Not stockedPush-in plug×1
- 425000227809Not stockedCable bushing×1
- 435000210832Not stockedThermostat×1
- 445000211190Not stockedWasher×2
- 455000227929Not stockedBurner pipe×1
- 465000227838Not stockedTerminal strip×1
- 475000227891Not stockedBurner air shutter×1
- 965000211051Not stockedLifting eye×4
- 975000211259Not stockedFilter×1
- 985000229061Not stockedCable bushing×1
- 995000211713Not stockedScrew×2
- 1005000211527Not stockedScrew×6
- 1015000211163Not stockedScrew×4
- 1025000229069Not stockedScrew×14
- 1035000229070Not stockedScrew×4
- 1045000229071Not stockedScrew×2
- 1055000229072Not stockedScrew×12
- 1065000229073Not stockedScrew×1
- 1085000211542Not stockedScrew×2
- 1105000229076Not stockedScrew×4
- 1145000229083Not stockedScrew×4
- 1155000211186Not stockedNut×6
- 1165000211187Not stockedNut×1
- 1175000229086Not stockedCap nut×4
- 1185000229087Not stockedNut×3
- 1195000229089Not stockedWing screw×1
- 1215000211190Not stockedWasher×4
- 1225000211563Not stockedWasher×6
- 1235000229093Not stockedDisc×4
- 1245000211196Not stockedWasher×2
- 1255000211203Not stockedClip nut×4
- 1265000229094Not stockedClamp×4
- 1285000229082Not stockedScrew×4
