HSH380s

HSH380S Engine Components (cont.) Diagram

Exploded parts diagram of the Engine Components (cont.) of a Wacker Neuson HSH380S, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 105200018132Not stocked
    Dipstick×1
  • 115200018127Not stocked
    Screw×1
  • 125200018128Not stocked
    Gasket×2
  • 135200018129Not stocked
    Screw×1
  • 145200018130Not stocked
    Gasket×1
  • 205200018133Not stocked
    Gauge×1
  • 305200018134Not stocked
    Oil plug×1
  • 405000179839Not stocked
    Oil pressure switch×1
  • 505200004741
    $22.04
    Filter-Oil, Kubota - 5200004741×1
  • 805000182021Not stocked
    O-Ring×1
  • 905000182020Not stocked
    Fuel filter element×1
  • 1005200018124Not stocked
    O-Ring×1
  • 1105200018123Not stocked
    Fuel filter cpl.×1
  • 1205200018131Not stocked
    Solenoid, stop×1
  • 1305200018126Not stocked
    Injection pump cpl.×1
  • 1405200018125Not stocked
    Glow plug×2
  • 1505200018118Not stocked
    Starter cpl.×1
