Internal Vib. IREN 57/048/240
IREN57/048/240 Hose connection cpl. Diagram
- 15100000096Not stockedSwitch box cpl.×1
- 25000203559Not stockedSupply line×1
- 55000126902Not stockedPower supply cable with plug×1
- SLEEVE-CABLE REINFORCEMENT - 5003008468×1
- Clamp - 5002007121×1
- 85000218249Not stockedProtective hose×1
- CONNECTOR-FLAT 26,0-4 - 5000203408×3
- CLAMP 201/J206-45X5/8 ,BAND-IT - 5002006823×1
- Clamp - 5002007121×1
- 175002006989Not stockedClamp×1
- 185000023511Not stockedProtective hose×1
- Diaphragm - 5003010141×1
- SWITCH 25A/380V/3P,ROCKER TYPE - 5002006994×1
- Flange - 5000067758×1
- WASHER A4.3 FLAT - 5000010628×2
- SCREW M4 X 16 SOC.HD. - 5000011570×1
- 245100000130Not stockedCheese head screw×1
- Oval head screw - 5100001329×4
- Clamp - 5000206365×1
- Oval head screw - 5100001330×2
- SEAL-RING 18 X 26 X 8,RUBBER - 5002006208×2
- SEAL-RING 17 X 26 X 0.8,PG21 - 5002003772×1
- CONNECTOR-BODY PG21 - 5003008328×1
- 315100002162Not stocked4 hole plug×1
- RING SEAL 16 X 20.5 X 0.8,PG16 - 5002000058×1
- CONNECTOR-BODY PG21 - 5003008191×1
- 345000124357Not stockedSwitch box cover cpl.×1
- Oval head screw - 5100001546×4
- LABEL-SYMBOL - 5000222083×2
