IRflex38/230/10

IRFLEX38/230/10 Internal Vibrator Diagram

Exploded parts diagram of the Internal Vibrator of a Wacker Neuson IRFLEX38/230/10, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 205000106055
    $37.97
    SLEEVE-DISTANCE - 5000106055×1
  • 305000219448Not stocked
    Washer×1
  • 405100006232
    $229.80
    Lower tube - 5100006232×1
  • 505000218501
    $356.29
    Tube-Upper - 5000218501×1
  • 605100006229
    $316.14
    Motor armature cpl. - 5100006229×1
  • 705100072285Not stocked
    Electric connection×1
  • 805002003795
    $0.26
    RING SEAL 10 X 13.5 X 0.8,PG9 - 5002003795×1
  • 1005002003792
    $0.48
    SEAL-RING 9 X 13.5 X 5.5 - 5002003792×1
  • 1105002003793
    $1.33
    CONNECTOR-BODY - 5002003793×1
