LTC4CP-LIGHT TOWER 60HZ

LTC4C-P Power Winch Diagram

Exploded parts diagram of the Power Winch of a Wacker Neuson LTC4C-P, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15000164829
    $1.30
    SCREW 1/2-13 X 1 ,HEX HD,GR5 - 5000164829×3
  • 25000155848
    $1.10
    WASHER 1/2 ,FLAT,SS - 5000155848×6
  • 35000164655
    $4.61
    WASHER-LOCK 1/2,SPLIT - 5000164655×3
  • 45000164656
    $1.32
    X-5000025619 NUT 1/2-13 - 5000164656×3
  • 55000163016
    $8.02
    SCREW 3/8-16X1-3/4 LG,SECURITY - 5000163016×1
  • 65000160741
    $3.06
    WASHER 3/8 - 5000160741×2
  • 75000160445
    $2.63
    Washer - 5000160445×1
  • 85000025649
    $0.04
    WASHER-LOCK 3/8,MED. - 5000025649×1
  • 95000155618
    $2.79
    X-5000025617 NUT 3/8 -16,HEX - 5000155618×1
  • 705000155536
    $18.54
    CLAMP-LOOM 3/8 - 5000155536×2
  • 715000163723
    $53.28
    CRANK-HAND - 5000163723×1
  • 725000163724
    $16.98
    WRENCH-SECURITY BOLT - 5000163724×1
  • 965000162318
    $1,688.95
    WINCH - 5000162318×1
