M3000/230-MOTOR

M3000/230 Motor Armature Set 230V Diagram

Exploded parts diagram of the Motor Armature Set 230V of a Wacker Neuson M3000/230, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15000074438Not stocked
    Stator×1
  • 25000077796
    $2.74
    TERMINAL-RCPT,FLAG 16-14,INS - 5000077796×1
  • 35000202517Not stocked
    End Sleeve For Strand×1
  • 45000013592
    $0.19
    PIN 5 X 24 ROLLED - 5000013592×2
  • 55000079335
    $301.62
    STATOR-ASSEMBLY 230V - 5000079335×1
