MG3 Por-Gen 120V 50Hz CEE-EN

MG3 Panel cpl. Diagram

Exploded parts diagram of the Panel cpl. of a Wacker Neuson MG3, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 1195000404067Not stocked
    Panel×1
  • 1205000407327Not stocked
    Panel, control×1
  • 1215000404069Not stocked
    Panel, rear×1
  • 1225000404024Not stocked
    Flange bolt×4
  • 1235000404071Not stocked
    Screw×6
  • 1245000404072Not stocked
    Washer×10
  • 1255000404073Not stocked
    Lock washer×10
  • 1265000404074Not stocked
    Nut×4
  • 1275000404075
    $15.62
    Bridge- Rectification - 5000404075×1
  • 1285000404076
    $11.75
    Switch Subassembly - 5000404076×1
  • 1295000404077
    $29.78
    Voltmeter - 5000404077×1
  • 1305000407328Not stocked
    Breaker×1
  • 1315000407329Not stocked
    Power socket adapter×2
  • 1325000404080
    $14.16
    Protector- Overcurrent - 5000404080×1
  • 1335000404081
    $6.97
    Terminal- Negative Electrode - 5000404081×1
  • 1345000404082Not stocked
    Terminal×1
  • 1475000407316Not stocked
    Terminal Kit×1
